These compressors are available in diesel/electric powered version. These compressors are designed & manufactured for various applications lihe DTH Drilling, Coal Drilling with Excavator Attachments, Oil & Gas Explorations, Pigging, Sand Blasting, Tunnelling, Quarrying, Piling & Road Constructions.
MODEL | DH750 |
Free Air Delivery | 750CFM |
Normal Working Pressure | 250PSIG |
Ambient Temperature Range | 5 - 54 ˚C |
Fuel Tank | - |
Air outlet valve with trolley (Wheeled) | - |
Air outley valve without trolley (Skid/ Rig) | 1 no of 2" |
Engine make | Ashok leyland |
Rated engine power | 320(236)HP(kW) |
Overall dimention with trolley (Wheeled) | - |
3280 X 1570 X 1780 L X B X H, MM | |
Dry weight of the Package with trolley (Wheeled) | - |
Dry weight of the Package without trolley (Skid/ Rig) | 3500Kg |
Mounting type | Skid |
